| Sampling Rate |
15 Hz |
| Display Refresh Rate |
15 Hz |
| Display Type |
High legibility TFT 320 x 240 pixel graphics LCD |
| Display |
15 mm numeric display. High resolution analog needle also can be chosen. |
| Compatible Detectors |
详询销售工程师 |
| Detector Type |
Low Power, High Power, Energy |
| Detector Input |
Up to 1.3 mA for Photodiode Sensors |
Accuracy |
±0.25 % (Full Scale) ± 20 p A |
| Maximum Detector Input Current |
1.4 mA |
| Maximum Input Power |
Detector dependent |
| Resolution |
18 bits plus sign |
| Wavelength Range |
Detector dependent |
| Analog Output |
0-1 V into 100 Ω, mono audio 2.5 mm jack (included) |
| Communication Interfaces |
None |
| Data Storage |
None |
| Battery Life |
14 hours typical between charges. |
| Battery |
Rechargeable Li-ion Batteries |
| Power Requirements |
DC 12 - 16 V, 1W |
| Length |
40 mm ( 1.6 in.) |
| Height |
8.4 in. ( 213 mm) |
| Width |
4.4 in. ( 113 mm) |
| Weight |
1.0 lb ( 0.47 kg) |
| RoHS |
Compliant |
| CE Certified |
Yes
常用配置参数
| Wavelength Range |
190 to 10,60nm |
| Power Range |
1 mW - 10 W |
| Pulse Energy, Maximum - w/o Attenuator |
1 nJ/cm2 |
| Calibration Uncertainty |
3 % |
| Calibration Uncertainty, w/ Attenuator |
N/A
|
|
